550FL Flybarless Rotorkopfsystem

• The 550FL Flybarless Rotor Head System utilizes extreme low CG design, effectively reduces resistance during 3D maneuvers, increased flight responsiveness and precision. In addition, the styling appearance harmony with red anodized and stainless color, bring out the high quality of helicopter.

• Suitable for T-REX 550L
• Must use with:
- 550 Main Shaft Set H55H003XXT
- 600PRO Metal Main Rotor Holder H60204
- 600 Feathering Shaft H60H001XXT or Feathering Shaft H60006


Content
• 1x 600FL Main Rotor Housing
• 1x Feathering Shaft Sleeve
• 2x 600DFC Head Damper
• 2x 600 Head Damper
• 2x 600FL Main Blade Grip Arm
• 2x 600FL Linkage rod
• 2x FL Metal Control Arm
• 2x Collar
• 4x FMR52ZZ Bearing (2x5x2.3mm)
• 4x 683ZZ Bearing (3x7x3mm)
• 10x 700 Elevator ball link
• 1x 600PRO Elevator ball link
• 10x Linkage rod holder
• 2x Ball link
• 2x Linkage ball B (M3x4mm)
• 2x 700N Linkage ball B (M3x4mm)
• 2x Socket screw (M4x8mm)
• 4x Socket screw (M2x5mm)
• 2x Socket screw (M3x16mm)
• 1x Socket button head collar screw (M4x24mm)
• 4x Socket button head collar screw (M3x6mm)
• 2x Washer
• 1x M4 nut
