Netzteil "eFuel" 1200W 50A 15 - 30 Volt - einstellbar - LCD Anzeige V2

SK-200015 - Netzteil eFuel 1200W 50A 15 - 30 Volt - einstellbar - LCD Anzeige V2 SkyRC SK-200015
Picture can be different from original item

The SkyRC eFuel 1200W power supply is one of the most powerful power supplies currently available with 1200W output power, an adjustable output voltage of 15-30V and active PCF.

It provides the perfect foundation for extremely powerful chargers or for powering multiple chargers or loads simultaneously.

The power supply can work with 240V input voltage as well as with 120V and can thus be used worldwide.

The output voltage can be adjusted via a wheel and is shown in the LCD display, as well as the output current.

By using the active PCF (Power Factor Corrector) the power factor can be increased to 95% - an efficient use of the mains current! This results in smaller current peaks and a larger, usable input voltage range. The caused disturbances are reduced to a minimum.

The two main outputs can supply up to 50 A each and the three auxiliary outputs up to 10 A each.

The LCD display shows the output voltage and current.

The power supply has two USB outputs of 5V and 2100mA, perfect for charging smartphone and tablet or similar.

The fan turns on automatically when the temperature reaches 50°C.


Technical Specifications:


• Dimensions: 305x170x85mm
• Weight: 3.08kg
• Input voltage: 100-240V AC
• Output voltage: 15-30V DC+0.5V
• Output current: 50A+1A
• Overload protection: =51A 500MS
• Fuse: 20A fuse
• LCD display
• Volt accuracy: +0.3V
• Current accuracy: +0.5A
• Power efficiency: 89
• Power Factor: > 0.98
• Overheating protection: <65°C
• Cooling method: Fan
• Operating Temperature: 0-40°C
309,90 €
incl. Tax
plus Shipping
 Item in stock
Delivery time ca. 1 to 3 days*
Item number

SK-200015

Manufacturer

SkyRC

Manufacturer-Nr.

SK200015-17

Packing weight3,9 Kg
EAN6930460001009
NewCondition
309.90EURInStock
SkyRCSK-2000156930460001009
